Application:

The Benchtop Climatic Chamber is widely used for testing small samples in industries such as plastics, automotive, and electronics. It is ideal for storage tests, temperature performance evaluations, and more.



Testing Standards:

IEC 60068-2-1          IEC 60068-2-2: 2007       IEC 60068-2-14

IEC 60068-2-30       IEC 60068-2-38                IEC 60068-2-78

ISO 16750-4               MIL-STD-810G                  ASTM E1457-13

JESD22-A101             GB/T 2423.1                       GB/T 2423.22



Features:

Compact design, space save

Lightweight, can be put on the table, suitable for labs and offices

Touch screen controller

Noise as low as 50 dB



Technical Parameters:

Model	SZ-A-36(A～G)	SZ-D-36(A～G)
Type	Temperature & Humidity Chamber	Temperature Chamber
Inner Size WxHxD (mm)	300x400x300 (36L)
Exterior Size WxHxD (mm)	850×900×860
Weight	160kgs
Temperature Range	-70℃～+150℃ (B:-40℃ D:-40℃ G:-70℃)
Humidity Range	20%～98%RH	/
Temperature / Humidity Fluctuation	±0.5℃; ±2.0%RH (*applicable to humidity chamber only)
Temperature / Humidity Deviation	±2℃ (≤200℃)；±3℃ (≤300℃) ≤±3.0%RH (>75%RH); ≤±5.0%RH (≤75%RH) (*applicable to humidity chamber only)
Heating/Cooling Rate	Average heating rate ≥ 4.0℃/min Average cooling rate ≥ 1.5℃/min (According to IEC60068-3-5, IEC60068-3-6)
Stack-able feature	Equipped with fixture parts allowing customer to stack over the same model chamber hassle-free without extra racks
Safety protection features	over temperature protection, auto pressure balancing protection, anti-water accumulation protection at the bottom of test zone, compressor overheat/over current/over pressure protection, condensation fan overheat protection，fan motor overload, short circuit protection, fan reverse protection, heater over temperature protection, short circuit protection, dry burn, water shortage protection (humidity chamber models only), earth leakage protection, overload protection, short-circuit protection, phase sequence protection
