Application:

Electronic equipment products



Testing standards:

IEC 60068-2-1         IEC 60068-2-2: 2007      IEC 60068-2-14

IEC 60068-2-30        IEC 60068-2-38          IEC 60068-2-78

ISO 16750-4           MIL-STD-810G           ASTM E1457-13

JESD22-A10           MIL-STD-2164           MIL-344A-4-16

MIL-2164A-19          NABMAT-9492           IPC-9701



Features:

Different stress can be set to screen the temperature change rate:5℃/min、10℃/min、15℃/min、20℃/min.

Meet the stress screening and lead-free process of electronic equipment products.

Wide temperature range from -70℃~+180℃



Technical Parameters:

Temp & Humidity	SZ-A-FX-225C/D/G	SZ-A-FX-408C/D/G		SZ-A-FX-608C/D/G		SZ-A-FX-1000C/D/G
Temp only	SZ-D-FX-225C/D/G	SZ-D-FX-408C/D/G		SZ-D-FX-608C/D/G		SZ-D-FX-1000C/D/G
Temp range	C: -20℃～+150/+180℃        D: -40℃～+150/+180℃          G: -70℃～+150/+180℃
Temp control accuracy	Temp resolution: 0.01℃ Temp fluctuation: ≤±0.5℃ Temp variation: ≤±2.0℃ Temp gradient: ≤±2.0℃
Heating/Cooling rate	F5≥5℃/min          F10≥10℃/min          F15≥15℃/min          F20≥20℃/min (Linear/Nonlinear)
Humidity range	20%～98%RH (by +20℃～+85℃) standard 10%～98%RH (by +20℃～+85℃) optional
Humidity control accuracy	Humidity resolution: 0.1%RH Humidity fluctuation: ≤±3%RH Humidity variation: ≤±3%RH (>75%RH); ≤±5%RH (≤75%RH)
Heater	Nichrome electronic heater
Refrigeration unit	Refrigeration method: Air cooling/ water cooling
Workspace dimensions	500*750*600 (W*H*D)		600*850*800 (W*H*D)		800*950*800 (W*H*D)		1000*1000*1000 (W*H*D)
Exterior dimensions	1000*1750*1300 (W*H*D)		1100*1850*1500 (W*H*D)		1300*1950*1500 (W*H*D)		1500*2000*1700 (W*H*D)
